What is the operation procedure of sterilizing pot?
Auther：980
Pubdate：2019-11-01 07:14:01
The operation process of sterilizing pot is very rigorous, and it needs to operate according to strict indicators. Bainxin machinery has sorted out a detailed step for you here:
First is the product ready, with food cart to the pot, and then put the pot had closed the door, and open, the inflatable cushion valve on the right side of security even closed the valve, the water into the pan, open the POTS and pans on the connected valves, put on the tank water all in a pot, at the time of water, open the valve on the boiler safety chain on the right side of the door, after closing drain, open the drain valve exhaust pipe water next to the blue valve.
Turn on the pressure automatic switch to fill the pot with about 0.05mpa pressure and then turn off. Open the circulating water pump, open the temperature automatic switch, open the trap switch to heat up the pot, and observe the drainage of the blue valve next to the trap. When the blue valve is not drained and starts to exhaust, close the blue valve.
After waiting for the temperature in the pot to display 100℃, the pressure automatic switch is turned on and the timer is adjusted. When waiting for the temperature to rise to the predetermined temperature, the time relay starts timing and enters the sterilization stage.
When the sterilizing time is reached, the buzzer will alarm. At this time, turn off the temperature automatic switch and turn off the steam trap.
Open the water inlet valve, in which the valve at the upper end should be small, open the blue valve and turn off the water flow, open the cooling pump, and then observe the pressure of the pressure gauge. If the pressure drops, turn off the water pump and wait for the pressure to be filled before opening until the pressure remains stable, and let the cooling pump keep running.
Turn off the pressure automatic switch when waiting for the temperature in the pot to show about 60 ℃. Turn off the circulating pump and cooling pump when the temperature shows about 40 ℃. Open the connecting valve of the upper tank and recycle the water into the tank. When the recycling is finished, there will be a sound of exhaust. At this time, close the valve.
Open the drain valve to let out all the air and water, and don't forget to turn it off.
After the safety chain head above the pot door falls off, open the right chain valve, close the inflatable mat valve and open the exhaust valve, open the pot door and take out the product with the food truck.
