Introduction of various steam traps in steam interlayer boiler
Auther：1116
Pubdate：2019-10-31 06:04:03
This pressure balance type steam trap body small volume, light weight, installation space is also small, corrosion resistant, not easy to be frozen by the cold, can be adjusted automatically according to the change of working pressure. When the condensate discharge temperature is below the saturated temperature, in order to maintain the steam space flow, must be in front of the steam trap cooling section.
Floating ball steam trap continuously discharge condensed water at saturated temperature with large displacement. Can also adapt to high and low load changes, not affected by pressure changes, equipped with automatic exhaust valve model, good exhaust performance. The model with the built-in broken steam lock is the only choice for steam lock applications. However, compared with the equilibrium type, this type tends to freeze when exposed and requires insulation.
There is also an inverted bucket trap, this valve body is relatively strong, simple structure, with a long service life. If a check valve is installed at the inlet, it can be used in an overheated steam system. Special attention should be given to the small hole in the top of the bucket, which can slowly discharge air. The hole should not be too large or it will leak steam under normal conditions. They also need to be kept warm in a cold environment.
Thermal-dynamic steam trap has simple structure, light weight, long service life and low installation cost. Large operating pressure range, no need to change the pressure and adjust the size of the replacement valve port, the only moving part stainless steel disc, to ensure reliable operation, reduce maintenance, with air removal disc, can prevent air obstruction. The trap makes a clicking sound when it is switched on and off to help determine whether the trap is working properly.
Low inlet pressure and high back pressure make the trap unable to work. Do not contain anti - lock disc model, in the machine when easy to produce air resistance. Exposure to low temperatures results in frequent valve switching and reduced service life. Heat shield must be added.
